Electrical junction boxes are required for all wall plugs ? In this installation the box and receptacle are installed high on the building exterior wall, under the soffit. This weatherproof box is designed to provide an outdoor electrical receptacle. Typical 4-inch Electrical Boxes used for Single (or more often) Duplex Electrical Receptaclesīelow-left we show a typical 4-inch metal junction box, and below-right a common and deeper plastic junction box.īelow: a weatherproof electrical box and receptacle mounted on a home in northern Minnesota. Installing a junction box that is too small is illegal and unsafe.
#Hubbell octagon box plaster rings install
It's likely to be permitted and safe to install a larger sized junction box than you need for an outlet or switch or wire splice, but you may need to purchase a special adapter-cover for the box in order to properly secure an electrical outlet therein. The box is carrying six wires in total: two "hot", two neutral, and two grounds.Īt above right in addition to aluminum wiring hazards the box is overcrowded. Typical electrical junction boxes used for receptacle installation to accommodates a single receptacle are 2" x 4" metal or plastic boxes of varying depth.Ĭhoose a deeper box if you have more than the minimum number of wires entering & leaving the box or it will be over-crowded and may violate building electrical codes.īelow are an older style steel electrical boxes nailed to wood framing in a building. Typical Electrical Boxes for Single Receptacles, Switches, or Splices This is an excerpt pertinent to wiring electrical receptacles and switches other wire sized and applications are given in the source NEC. NEC 314.16(B) Electrical Box Volume Required Per Conductor (wire)įree space within the box for each conductor Table of Electrical Box Sizes vs Number of Wires Allowed GANG BOXES for MULTIPLE SWITCHES or RECEPTACLES.If the clearance between the metal box and other live electrical parts is too small, arcs and short circuits could occur, as we depict in this sketch courtesy of Carson Dunlop Associates (found at page bottom, Click to Show or Hide).If the junction box is too small you face several problems such as crowding which forces wires to be jammed and bent into the box, increasing the chance of a loose connection or damaged wiring, and worse, arcing.We give some basic electrical box size examples just below.
#Hubbell octagon box plaster rings code
The National Electrical Code Article 314 contains complete details and tables of electrical box sizes in dimensions and cubic inches and should be consulted for complete accuracy because the actual size of the box required, in cubic inches, depends on the number of wires that will be within that enclosure.The proper sized and type of junction box must be used to house the electrical receptacle, must be properly secured in the wall, and must be located at the proper height from the floor.Choose the Proper Electrical Junction Box When Adding a Receptacle We also provide an ARTICLE INDEX for this topic, or you can try the page top or bottom SEARCH BOX as a quick way to find information you need. Electrical receptacles (also called electrical outlets or "plugs" or "sockets") are simple devices that are easy to install, but there are details to get right if you want to be safe.
#Hubbell octagon box plaster rings how to
This article series describes how to choose, locate, and wire an electrical receptacle in a home. Here we describe matching 15-Amp receptacles to 15-Amp circuits, 20-Amp receptacles to 20-Amp circuits, two-wire receptacles where no ground is present, GFCI and AFCI electrical receptacles, and the proper electrical box to hold and mount these devices. How to choose the right type of electrical receptacle when adding or replacing a wall outlet in a building. Guide to types of electrical receptacles (wall "outlets" or "wall plugs"): We have no relationship with advertisers, products, or services discussed at this website. InspectAPedia tolerates no conflicts of interest.
